| Cab Control | Forward Tilt Cab |
| Seating | Driver + 2 Passenger |
| Type/Extras | Sleeper Cab with Aircon, Radio with USB, Suspension seat |
| Make & Model | WP10.290E32 |
| Capacity | 9 726 cm3 |
| Layout & Type | 6 cylinder in line, water cooled, turbo charged & intercooled |
| Power @ r/min (kW) | 213 @ 2 200rpm |
| Torque @ r/min (Nm) | 1 160 @ 1 200 – 1 600 |
| Make & Model | FAW CA9TB160M |
| Type | 9 Speed Manual Syncromesh |
| Forward Ratios | 14.34; 10.04; 7.10; 5.05; 3.71; 2.70; 1.92; 1.36; 1.0 |
| Reverse Ratio | 8.63 |
| Diameter | 430 mm |
| Type | Single Plate |
| Operation | Hydraulic-Air Assisted |
| Gear Ratio | 23:1 |
| Type | Recirculating Ball |
| Operation | Power Assisted |
| Gradeability @ V | Max 27% |
| Permissible Road Speed | 80km/h |
| Front Axle | I- Beam section (Forged Steel) |
| Rear Axle – Gearing Type | Single Reduction |
| Rear Axle Ratio | 4.1:1 |
| System Type | Full Air – Dual Circuit with ABS |
| Park/Emergency System | Spring Brakes/Rear Booster |
| Number | One |
| Total Capacity | 400 Litre |
| System Voltage & Type | 24V Negative Earth |
| No. of Batteries | Two X 12V |
| Type | Straight Ladder Type – Riveted |
| Front Suspension | Semi-Elliptical Leaf Spring with Double Acting Shock Absorbers |
| Rear Suspension | Semi-Elliptical Leaf Springs |
| Tyre Size | 315/80R22.5-18PR |
| Rim Size | 9.00 X 22.5 |
| Type | Tubeless Radial |
| Manufacturer’s Gross Vehicle Mass (GVM) | 28 000 |
| Manufacturer’s Gross Combination Mass (GCM) | 50 000 |
| Manufacturer’s Front Axle Mass (GA Front) | 7 700 |
| Manufacturer’s Rear Axle Mass (GAU Rear) | 20 300 |
| Permissible Gross Vehicle Mass (V) | 25 700 |
| Permissible Gross Combination Mass (D/T) | 50 000 |
| Permissible Front Axle Mass (A Front) | 7 700 |
| Permissible Rear Axle Mass (A Rear) | 18 000 |
| Unladen Front Axle Mass (T Front) | 4 184 |
| Unladen Rear Axle Mass (T Rear) | 4 394 |
| Unladen Mass Total (Tare) | 8 578 |
| Body and Payload Allowance | 17 122 |
| Wheelbase (WB) | 5 100 + 1 350 |
| Overall Length (OL) | 9 825 |
| Cab Length (A) | 2 325 |
| Overall Width (OW) | 2 500 |
| Overall Height (OH) | 2 900 |
| Front Overhang (D) | 1 375 |
| Rear Overhang (ROH) | 2 000 |
| Cab to Rear Axle (CA) | 7 825 |
| Recommended Body Length | 7 600 |
| Cab to End of Chassis (F) | 7 810 |
| Minimum Turning Radius | 10 000 |
| Minimum Turning Diameter | 20 000 |
| Ground Clearance | 300 |
| Track – Front | 2 050 |
| Track – Rear | 1 847 |
| Chassis Outer Width | 865 |
| Chassis Inner Width | 640 |
